HKM choses Paul Wurth for construction of compression and injection system

by David Fleschen

Stahlerhstellung: Flüssiger Stahl läuft aus dem Schmelzofen

With the aim to improve the CO2 balance of their steel plant operations located at Duisburg Huckingen in the Ruhr region in Germany, Hüttenwerke Krupp Mannesmann GmbH (HKM) has chosen Paul Wurth S.A. for engineering and construction of a coke oven gas (COG) compression and injection system for their two blast furnaces “A” and “B”.

The new injection system will complement the already existing natural gas (NG) injection system, which was taken into operation in 2003 respectively in 2005 as well as the existing pulverised coal injection (PCI) system, which was commissioned in 2009. The new COG injection system will provide up to 30 000 Nm3/h of COG per blast furnace. Injection of mixed COG and NG of up to 60 000 Nm3/h per blast furnace will be possible.

The corresponding plant will be installed in a brownfield area in the existing steelworks. Aside of all engineering, the order foresees supply, erection and commissioning of two compressors of geared turbo type, an appropriate noise insulated housing for the compressor station and all process piping for the supply of the COG up to the (2 x 30) hot blast tuyeres of the blast furnaces. Civil works will be executed by HKM. Start of commissioning activities is envisaged for the last quarter of 2022.

HKM operates an integrated steelworks consisting of a sinter plant with a design capacity of 6 mtpy, two coke oven batteries for a design capacity of 2.32 mtpy, blast furnaces “A” and “B” with a combined design capacity of 5.2 mtpy of hot metal, and a BOF steelmaking shop with continuous casters. With around 3 000 employees, HKM produces about 4 million tons of steel per year, which comes in the form of slabs and round blooms for the tube and pipe industry. The level of savings may vary depending on the availability of COG and the price of CO2 certificates within the European carbon emissions trade scheme. In any case, HKM will significantly reduce the carbon footprint of their integrated steelmaking plant.

For HKM and for Paul Wurth, the present project is an important confirmation of both company’s leading position in readily available technologies for CO2 emission reduction from blast furnace operations.

Source: Paul Wurth, Fotolia
